- Size: 55 CBM
- Place of Origin: China
- Brand Name: SINOTRUK
- Model Number: ZZ4257N3241W
- Weight: 9200.000 kg
Specification for SINOTRUK HOWO Dump Truck
Tractor truck model | ZZ4257S3241W | |
Cab | Model | HW76 |
Type | Low cab | |
Engine | Model | WD615.69 |
Rated power kW/rpm | 213/2200 | |
Maximum torque Nm/rpm | 1160/1100-1600 | |
Displacement L | 9.726 | |
Clutch | 430 Diaphragm spring clutch | |
Transmission | China National heavy duty truck HW Series | |
Front axle | HF7 | |
Driving axle | HW1697 | |
Steering system | ZF8098 | |
Electrical system | Voltage: 24V: 2 12V/165Ah | |
Tire | 12.00-20 Or11.00-20 | |
Fuel tank capacity L | 400 | |
Curb weight kg | 9210 | |
Total mass kg | 25000 | |
Trailer mass kg | 32400 | |
Saddle allows loading weight kg | 15660 | |
Overall dimensions (l x w x h) mm | 6800x2496x3563 | |
Wheel base mm | 3200+1400 | |
Front suspension / Rear suspension mm | 1500/725 | |
Track width (front / After) mm | 2022/1850 | |
Minimum ground clearance mm | 267 | |
Approach angle / Angle of departure | 16/70 | |
SINOTRUK HOWO Dump Truck Details Pictures:
Our Main Products:
√ Semi Trailer:Low bed semi trailer, container transport semi trailer, cargo trailer,dump
semi trailer,tank semi trailer, special semi trailer.
√ Dump/Tipper Truck:4x2 Tipper/Dump truck,6x4 Tipper/Dump truck,8x4 Tipper truck.
√ Tractor Truck : 4x2 Tractor Truck,6x4 Tractor Truck,8x4 Tractor Truck.
√ Cargo Truck:4x2 Cargo Truck ,6x4 Cargo Truck ,8x4 Cargo Truck.
√ Concrete Mixer Truck: 4x2 Concrete Mixer Truck ,6x4 Concrete Mixer Truck,8x4 Mixer
√ Water Tank Truck:4x2 Concrete Mixer Truck ,6x4 Concrete Mixer Truck,8x4 Mixer
√ Fuel Oil Tank T ruck: 4x2 Fuel Oil Tank Truck ,6x4 Fuel Oil Tank Truck ,8x4 Tank Truck
SINOTRUK HOWO Dump Truck Spare Parts Sales Service:
